| 브랜드 이름: | Xingweihan |
| 모델 번호: | d (n) b---100, d (n) b--160, d (n) b--200, d (n) b--250 |
| MOQ: | 1 |
| 가격: | USD10000-USD12000 |
| 지불 조건: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| 공급 능력: | 50 세트/월 |
The design philosophy of this device is to create a safe, comfortable, and efficient model of human-machine collaboration. We prioritize the convenience and safety of operation with a spacious work area and clear fixture positioning, making workpiece handling smooth and natural.
The dual welding head layout has been optimized through ergonomics to prevent operator strain. Equipment features include dual hand start buttons or safety light barriers to ensure welding only begins when hands are safely positioned. The low spatter welding process and efficient smoke exhaust system create a cleaner, healthier work environment.
| Items Models | DN(B)-100 | DN(B)-160 | DN(B)-200 | DN(B)-250 |
|---|---|---|---|---|
| Rated power (KVA) | 100 | 160 | 200 | 250 |
| Power input(V) | 3φAC 380V | 3φAC 380V | 3φAC 380V | 3φAC 380V |
| Max. short circuit current (KA) | 30 | 35 | 40 | 45 |
| Duty cycle(%) | 50 | 50 | 50 | 50 |
| Max. force(N) | 6000 | 6000 | 10000 | 15000 |
| Electrode length(MM) | 450 | 450 | 450 | 500 |
| Working stroke(MM) | 80 | 80 | 80 | 80 |
| Cooling consumption(L/min) | 20 | 20 | 20 | 20 |
| Max. welding capacity(MM) | 3.0+3.0 | 4.0+4.0 | 5.0+5.0 | 6.0+6.0 |
The shipment is 15 days after getting deposit, but customized machines should be more than 25 days.
Yes, each step of production products will be inspected by QC department before shipping.
Yes, we are factory, all machine is made by ourself and we can provide customize service according to your requirement.
Please send us inquiry to our email, and we will give you a PI to send us payment.
You can send a mail for us and call us.
We always ship by air and sea in the mean time.
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane.
T/T, Western Union, PayPal, L/C, D/A, etc.
